Inductores fijos
| Foto | N.º de Parte del Fabricante | Disponibilidad | Cantidad | Hoja de Datos | Serie | Paquete/Caja | Embalaje | Estado del producto | Tipo | Material - Núcleo | Inductancia | Tolerancia | Clasificación de corriente (amperios) | Corriente - Saturación (Isat) | Blindaje | Resistencia de CC (DCR) | Q a frecuencia | Frecuencia: autorresonante | Clasificaciones | Temperatura de funcionamiento | Frecuencia de inductancia - Prueba | Características | Tipo de montaje | Proveedor Dispositivo Paquete | Tamaño/Dimensión | Altura - Asentado (Máx.) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
MSA543R3M0S001INDUCTANCE 3.3 H TOL 20% Coilmx |
48,000 |
|
Tabla de datos |
MSA | 2-SMD | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 3.3 µH | ±20% | - | 4A | Unshielded | 30mOhm Max | - | - | - | -55°C ~ 125°C | 100 kHz | - | Surface Mount | 2-SMD | 0.228" L x 0.205" W (5.80mm x 5.20mm) | 0.189" (4.80mm) |
|
|
MSA54100M0S001INDUCTANCE 10 H TOL 20% Coilmx |
6,000 |
|
Tabla de datos |
MSA | 2-SMD | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 10 µH | ±20% | - | 2.6A | Unshielded | 72mOhm Max | - | - | - | -55°C ~ 125°C | 100 kHz | - | Surface Mount | 2-SMD | 0.228" L x 0.205" W (5.80mm x 5.20mm) | 0.189" (4.80mm) |
|
MS1050100MS001INDUCTANCE 1.0 H TOL 20% Coilmx |
145,000 |
|
Tabla de datos |
MS | 2-SMD | Tape & Reel (TR) | Active | - | Ferrite | 10 µH | ±20% | 5.5 A | 8.5A | Shielded | 30mOhm Max | - | - | - | -55°C ~ 125°C | 100 kHz | - | Surface Mount | 2-SMD | 0.439" L x 0.394" W (11.15mm x 10.00mm) | 0.197" (5.00mm) |
|
|
MS10403R3MS001INDUCTANCE 3.3 H TOL 20% Coilmx |
97,000 |
|
Tabla de datos |
MS | 2-SMD | Tape & Reel (TR) | Active | - | Ferrite | 3.3 µH | ±20% | 10 A | 16A | Shielded | 12mOhm Max | - | - | - | -55°C ~ 125°C | 100 kHz | - | Surface Mount | 2-SMD | 0.427" L x 0.394" W (10.85mm x 10.00mm) | 0.157" (4.00mm) |
|
|
MS13604R7MS001INDUCTANCE 4.7 H TOL 20% Coilmx |
7,000 |
|
Tabla de datos |
MS | 2-SMD | Tape & Reel (TR) | Active | - | Ferrite | 4.7 µH | ±20% | 13 A | 18A | Shielded | 18mOhm Max | - | - | - | -55°C ~ 125°C | 100 kHz | - | Surface Mount | 2-SMD | 0.537" L x 0.496" W (13.65mm x 12.60mm) | 0.236" (6.00mm) |
|
|
MS13603R3MS001INDUCTANCE 3.3 H TOL 20% Coilmx |
6,000 |
|
Tabla de datos |
MS | 2-SMD | Tape & Reel (TR) | Active | - | Ferrite | 3.3 µH | ±20% | 16 A | 22A | Shielded | 2.5mOhm Max | - | - | - | -55°C ~ 125°C | 100 kHz | - | Surface Mount | 2-SMD | 0.537" L x 0.496" W (13.65mm x 12.60mm) | 0.236" (6.00mm) |
|
MTP2915150ML01INDUCTANCE 15 H TOL 20% Coilmx |
320 |
|
Tabla de datos |
MTP2915 | Radial | Tray | Active | Drum Core, Wirewound | Ferrite | 15 µH | ±20% | 30 A | 16A | Unshielded | 3mOhm Max | - | - | - | -55°C ~ 125°C | 100 kHz | - | Through Hole | - | 1.102" L x 0.748" W (28.00mm x 19.00mm) | 0.610" (15.50mm) |
|
|
MTP2915220ML01INDUCTANCE 22 H TOL 20% Coilmx |
320 |
|
Tabla de datos |
MTP2915 | Radial | Tray | Active | Drum Core, Wirewound | Ferrite | 22 µH | ±20% | 30 A | 10A | Unshielded | 3mOhm Max | - | - | - | -55°C ~ 125°C | 100 kHz | - | Through Hole | - | 1.102" L x 0.748" W (28.00mm x 19.00mm) | 0.610" (15.50mm) |
|
|
MTP2915270ML01INDUCTANCE 27 H TOL 20% Coilmx |
320 |
|
Tabla de datos |
MTP2915 | Radial | Tray | Active | Drum Core, Wirewound | Ferrite | 27 µH | ±20% | 30 A | 8A | Unshielded | 3mOhm Max | - | - | - | -55°C ~ 125°C | 100 kHz | - | Through Hole | - | 1.102" L x 0.748" W (28.00mm x 19.00mm) | 0.610" (15.50mm) |
|
|
MTP2915100ML01INDUCTANCE 10 H TOL 20% Coilmx |
320 |
|
Tabla de datos |
MTP2915 | Radial | Tray | Active | Drum Core, Wirewound | Ferrite | 10 µH | ±20% | 30 A | 28A | Unshielded | 2.5mOhm Max | - | - | - | -55°C ~ 125°C | 100 kHz | - | Through Hole | - | 1.102" L x 0.748" W (28.00mm x 19.00mm) | 0.610" (15.50mm) |
